The 60x60mm DC brushless blower fan is designed for medium-sized electronic devices requiring efficient heat dissipation. The fan offers multiple voltage options, including 5V, 12V, and 24V, to meet various application needs. Its compact design delivers strong airflow in limited spaces, while the low-noise operation, with a noise level as low as 27 dB(A), makes it ideal for environments requiring quiet operation. Additionally, the fan features a durable structure with a long lifespan, making it suitable for both household and industrial equipment.
Date Sheet
Model: DB6025
Fan Type: DC Blower
Motor: Brushless DC Motor
Bearing Type: Ball/Oil/Sleeve, Optional
Blade Material: PBT
Frame Material: PBT
Certification: UL CE CCC
Control Mode: PWM, VSP, Temperature Control, Constant Speed
Protection Performance: Lock Protection, Soft Start, IP Maximum IP68
Output Signal: FG RD LD
Insulation Class: B
Insulation Resistance: 10MΩ/500V DC
Voltage Strength: 2Min/500V AC/5mA
Humidity Range: 20%-85%
Operating Temperature: -10℃/+60℃
Maximum of Life Expectancy: 50000 Hours
