The 120x120x25mm DC axial fan is a high-efficiency, durable cooling solution widely used in industrial and commercial equipment. The fan supports multiple voltage options (12V, 24V, 48V), making it suitable for various cooling needs. Its dual ball bearing design ensures a lifespan of up to 70,000 hours, ideal for environments requiring continuous operation, such as servers, communication equipment, industrial automation systems, and data centers. The fan offers airflow of up to 107 CFM and operates with low noise, effectively maintaining efficient cooling while minimizing noise interference. Both the housing and blades are made from flame-retardant materials that comply with UL94V-0 standards, ensuring safety.
Date Sheet
Model: DC-12025
Fan Type: Axial Fan
Motor: Brushless DC Motor
Bearing Type: Ball/Oil/Sleeve, Optional
Blade Material: PBT
Certification: UL CE CCC
Control Mode: PWM, VSP, Temperature Control, Constant Speed
Protection Performance: Lock Protection, IP Maximum IP68
Output Signal: FG RD LD
Insulation Class: Class B
Insulation Resistance: 10MΩ/500V DC
Voltage Strength: 2Min/500V AC/5mA
Humidity Range: 20%-85%
Operating Temperature: -10℃/+60℃
Maximum of Life Expectancy: 70000 Hours
