The 80x80x38mm DC axial fan is a high-performance cooling solution designed for industrial and commercial applications that require high airflow and high static pressure. The fan offers multiple voltage options (12V, 24V, 48V) and can operate at speeds of up to 12,000 RPM, delivering maximum airflow and high static pressure. This makes it ideal for cooling high-density electronic devices, battery modules, heat dissipation modules, industrial automation systems, communication equipment, and server cooling. The fan features a dual ball bearing design with a lifespan of up to 70,000 hours and is certified with ROSH, CE, REACH, and UL. Its IP67 rating ensures durability and stability in harsh environments.
Date Sheet
Model: DC-8038
Fan Type: Fan Type
Motor: Brushless DC Motor
Bearing Type: Ball/Oil/Sleeve, Optional
Blade Material: PBT
Certification: UL CE CCC
Control Mode: PWM, VSP, Temperature Control, Constant Speed
Protection Performance: Lock Protection, IP Maximum IP68
Output Signal: FG RD LD
Insulation Class: Class B
Insulation Resistance: 10MΩ/500V DC
Voltage Strength: 2Min/500V AC/5mA
Humidity Range: 20%-85%
Operating Temperature: -10℃/+60℃
Maximum of Life Expectancy: 70000 Hours
